Next Generation Bicycle Rack

TOUGH AS A BULL, LIGHT AS A FEATHER



Important Announcement!!

OPEN HOUSE TO SHOW IMPROVED PRODUCTION MODEL ON JULY 30 SATURDAY 10:00AM TO 5:00PM

LATEST UPDATES AS OF AUGUST 2022

As the result of playing with heavy e-bikes I'm Very exited to share pictures of improved version of the Light Bull.

What was changed:

- NEW CAM CLAMPING SYSTEM
- NEW CHAIN STAY SUPPORT
- Heads mounting tubing went from 1.5" to 2"
- Bottom Bracket support went from plastic to strong welded aluminum structure
- Down tube vertical support went from single 5/8" round tubing to double     1/2"x1" rectangular tubing
- Down tube horizontal support went from 5/8" round tubing to 20mm (over   3/4") round tubing
- 5 plastic components was eliminated - Head mounting tubing and diagonal   main tubing has now welded end caps
- Bolt spread connecting heads to vertical plates went from 1.6" to 2.5" (stiffer-   stronger)
- Rubber "V" jaws went from 2.25" to 2.75" in length . Cavity in center of jaws
was incorporated for better grab.
- Jaws movement was improved -is more smooth and precise.
- Handle position was changed from vertical to horizontal - more space for   supports adjustments.

All above makes Light Bull simpler, stronger and more elegant.

3 INSTALL OPTIONS TO CHOOSE



PROMO VIDEO

HOW IT WORKS

RACK BUMP TEST

Mountain Biking by the Lake

DESIGN




KEY FEATURES

LIGHT

A combination of lightweight materials use and the creative design makes the device as light as 19 lbs.

STRONG & STIFF

Short tube design combined with careful design means Lighbull does not warp and rattle as you drive. No matter what bike you attach.

COMPACT

The device's exceptionally small overall dimension allows that to be folded and stored in a car trunk or garage shelf.​

QUICK INSTALL

Securing the bike in place on the rack comes down to two operations, which is tightening the knob that activates clamping jaws and tightening down tube holding strap.

INSTANT LOCKING

After the locking knob is removed, the rack and bike are locked and secured.

VERSATILE

Lightbull can accommodate nearly all bike types, Men & Womens, Fat Tire bikes with no extra equipment or after market accessories.

EASY STORAGE

LightBull can be folded into a small package that easily fits in your trunk or garage shelf. It is so small you can store it with luggage in most car trunk.

ACCESSORIES INCLUDED

Lightbull comes with all you need - no up-selling required. Each Lightbull comes with:

•Safety Pin •Storage Bag •Two Locking Knob Keys •Two front wheel Stabilizers

THE LIGHTBULL GALLERY

Shows the design with up to date improvements

IMG_3871
IMG_3868
IMG_3865
IMG_3873
IMG_3894
IMG_3893
IMG_3892
IMG_3889
IMG_3888
IMG_3886
IMG_3897
IMG_3895
IMG_3878
IMG_3879
IMG_3876
IMG_3880
20220721_191430



COMPETITOR COMPARISON



INSTALLATION

Bicycle Shop

TECHNICAL SPECIFICATIONS

  • Max number of bikes:  2

  • Load capacity: 130 lb

  • Max bike weight:  75   lb

  • Dimensions:  30 x 18 x 11 in

  • Folded dimensions: 24 x 15 x 11 in

  • Weight: 19  lb

  • Max tire width: No restrictions

  • Max wheel size (diameter): No restrictions

  • Max wheelbase: No restrictions

  • Distance between bikes: About 12 in  ( varies slightly  depended on bike type)

  • Carbon frame compatible: YES

  • Tilt function (with bikes): YES

  • Fits 1.25" receivers: Load capacity is 100 lb for 1.25" receivers

  • Fits 2" receivers: YES

  • One Key System compatible: YES

  • Bike lock included: YES

  • Receiver lock included: YES
